Label printers SQUIX
Flexible printers for industrial applications

reliable and fast printing
accurate print images
easy to operate
compact design
maximum quality standards

They are for use in a wide range of applications. They have been developed with a constant focus on easy and intuitive operation as well as high reliability.

The print mechanics and the chassis are made from high-quality materials and perfectly match in shape and function. A large number of peripherals and software enable customer-specific solutions.

Whether operated stand-alone, linked to a PC or in a network – the rugged printers are always up to the mark. A powerful processor results in print jobs performed quickly and labels provided straight away.

Sample applications

PCB labeling

Type plate labeling

Cardboard and pallet labeling

Label printers with left-aligned material guidance

designed for printing in different print widths on various materials

vergrößern

Slim ones
to print small labels

1.1, 1.2 Label printer	SQUIX 2
Printable resolution dpi	300	600
Print speed up to mm/s	250	150
Print width up to mm	56.9	54.1

vergrößern

Universal ones
Best-selling industrial device with a wide range of accessories.

1.3, 1.4 Label printer	SQUIX 4.3		SQUIX 4
Printable resolution dpi	203	300	300	600
Print speed up to mm/s	300	300	300	150
Print width up to mm	104	108.4	105.7	105.7

NEU Basic devices may be provided with an integral cutter.

vergrößern

Wide ones
to print Odette, UCC and GS1 labels in logistics applications

1.5, 1.6 Label printer	SQUIX 6.3
Printable resolution dpi	203	300
Print speed up to mm/s	250	250
Print width up to mm	168	162.6

Basic device
providing a tear-off plate

They print on labels or on continuous materials wound on rolls or fanfold. Materials are torn off on a jagged plate. Cutting is an option, so is external rewinding.

Peel-off device
providing a rewinder internally

Peeling off labels is a feature added to a basic version. Labels are separated from the liner after printing to be removed by hand or by an applicator.

cab Label printer A8+ the extra wide one

vergrößern

The extra wide one
to print pallet or barrel labels

Label printer	A8+
Printable resolution dpi	300
Print speed up to mm/s	150
Print width up to mm	216

More information to Label printer A8+

See also:

SQUIX label printers with centered material guide

Material guide
centered

SQUIX 4 M
especially for very small labels or slim continuous materials

SQUIX 4 MT
especially for continuous textil materials

Etikettendrucker SQUIX -für industrielle Anwendungen

Play

Video: Label printer SQUIX

designed for industrial application

View Video

Want to learn more?

Label printers SQUIX

Ask for an offer free of charge and without obligation:

Request a quote

Learn more:

Read the product brochure (PDF)

Label printer with left-aligned material guidance

: Label printer SQUIX 4 P,
peel-off device providing a rewinder internally

as a peel-off device providing a rewinder internally

1 Hinged cover
Material stock can be checked and entire printing processes followed through a large panoramic window.

2 Plungers
One is fixed on the inside. To get a good print image, the second one is moved to the outside margin of a label.

3 Rugged metal chassis
made of cast aluminum to assemble all the units

4 Coated print rollers
Synthetic rubber is a standard to get highly accurate print images. Silicone coating is an option for extra long service life.

5 Peel-off function
to separate labels from the liner. A powered guide roller and a pinch roller enable highly accurate imprint and peel-off.

6 Peripheral port
to plug additional modules easily and quickly. They are screw-fixed.

7 Ribbon holder
Ribbons are quick and easy to replace using three-part tightening axles.

8 Roll holder
Constant tension by means of the margin stop (spring-mounted, screw-capped) while material is fed

9 Internal rewinder
to wind labels or liners with or without a cardboard core on peel-off devices. Materials are easy to handle using a three-part tightening axle.

10 Rocker
Suspension and Teflon-made guide rollers reduce traction and improve the accuracy of print images.

11 Material guide
assembled to the rocker. By a user turning the rotary knob, the stop moves to the margin of a label.

Print image accuracy
The smaller a label, the higher are the demands. Using slip correction, print offset can be reduced by ±0.2 mm.

Operation panel

Self-explanatory symbols help with the device settings and enable a printer to be operated intuitive and easily.

Operation panel 1 LED: Power ON

2 Status bar: reception of data, record data stream, pre-warning to a ribbon ending, SD memory card / USB memory stick plugged, Bluetooth, WLAN, Ethernet, USB slave, time

3 Printer status: ready, pause, number of labels printed in a print job, label in peel-off position, external start signal awaited

4 USB port to plug a service key or a memory stick, to transfer data to the IFFS memory

5 USB WLAN stick 2.4 GHz 802.11b/g/n enclosed in the scope of delivery; In hotspot mode, mobile devices can connect directly to a printer via WLAN.

6 Operation

Cutter / perforation cutter: cutting
External rewinder: wound outside or inside
Tear-off mode / peel-off mode: printing a label
Applicator: printing and labeling in individual steps

Jump Jump to menu

Reprint Reprint last label

Interrupt and continue print job

Stop Stop and delete all print jobs

Label feed

vergrößern
Setup options

vergrößern
Printing parameters

vergrößern
Print position Y

vergrößern
Print speed selection

vergrößern
Video tutorials

External operation panel

same functionality as on the printer

display in landscape or portrait mode

Users are free to choose whether to operate the external panel or the one installed on the printer.

USB 2.0 Hi-Speed device to connect a printer

1 LED: Power ON

2 USB port to plug a service key or a memory stick, to transfer data to the IFFS memory

3 Connecting USB cable, lengths 1.8 m to 16 m. If length succeeds 3 m, use only specified cables. For dimensions see assembly instructions

Print heads

A print head can be replaced by any other one, provided they are of equal width. They are detected and calibrated by the CPU automatically.
Major data such as the operational performance, maximum operational temperatures and heat energies are kept in memory on a print head. The data can be read at the premise.

Print heads provided for SQUIX 2, SQUIX 4 - 300, 600 dpi
to print sharp-edge images
to print small fonts and graphics on typeplates
to print on materials that imply high energy needs

Print heads provided for SQUIX 4.3, SQUIX 6.3 - 203, 300 dpi
durable
to operate in harsh environments, thermal direct printing

Maintenance

Label sensors
unlock by touch to be pulled out.

Print heads
require few steps to be replaced. In general, no adjustments are needed.

Print rollers
are quick and easy to remove using a screw.

ONE tool
is provided ready on a device to replace all the components and assemble periphery.

Want to learn more?

Label printers SQUIX

Ask for an offer free of charge and without obligation:

Request a quote

Learn more:

Read the product brochure (PDF)

Technical data SQUIX with SQUIX M and SQUIX MP by comparison (PDF)

Typical Typical Possible Standard Option Option

Label printer	SQUIX 2		SQUIX 4.3		SQUIX 4		SQUIX 6.3
	1.1		1.2				1.3
Material feed	Left-aligned
Printing method: Thermal transfer
Printing method: Thermal direct		-				-
Printable resolution dpi	300	600	203	300	300	600	203	300
Print speed up to mm/s	250	150	300	300	300	150	250	250
Print width up to mm	56.9	54.1	104	108.4	105.7	105.7	168	162.6
Start of printing: Distance to locating edge mm	2		2.8	1.2	2		0.5	3.2
Material¹⁾
Paper, cardboard, plastics PET, PE, PP, PI, PVC, PU, acrylate, Tyvec
Shrink tubes ready-for-use	-
Packing on rolls, fanfold
Packing Roll diameter up to mm	205
Packing Core diameter mm	38.1 - 76
Packing Winding	outside or inside
Labels Width mm	4 - 63		20 - 116				46 - 176
Labels Height excl. label backfeed²⁾ from mm	4		4				6
Labels Height incl. label backfeed²⁾ from mm	4		6				12
Labels height incl. label backfeed / peel-off from mm	6		6				12
Labels Thickness mm	0.03-0.6
Liner material Width mm	24 -67		24 - 120				50 - 180
Liner material Thickness mm	0.03-0.16
Continuous material Width mm	24 - 67		24 - 120				50 - 180
Continuous material Thickness mm	0.05-0.5
Continuous material Weight (cardboard) up to g/m²	300
Shrink tubes Width ready-for-use up to mm	-		120				-
Shrink tubes Thickness up to mm	-		1.1				-
Ribbon³⁾ Ink side	outside or inside
Ribbon Roll diameter up to mm	90
Ribbon Core diameter mm	25.4
Ribbon Variable length up to m	600
Ribbon Width mm	25 - 67		25 - 114				50 - 170
Internal rewinder in peel-off version
Outside diameter up to mm	142
Core diameter mm	40
Winding	outside
Printer sizes and weights
Width x Height x Depth mm	200 x 288 x 460		252 x 288 x 460				312 x 288 x 460
Weight kg	9		10				14
Label sensor indicating the position
Gap sensor for	labels or punch marks and end of material, print marks on transparant materials
Reflective sensor reflex from below or top for	labels and end of material, print marks on non-transparent materials
Distance of sensor to locating edge left-aligned mm	5 - 26		5 - 60				5 - 60
Material passage up to mm	2
Electronics
Processor 32 bit clock rate MHz	800
Main storage (RAM) MB	256
Data storage (IFFS) MB	50
Slot for SD memory card (SDHC, SDXC) up to GB	512
Battery for time and date, real-time clock
Data memory when power is switched off (e.g. serial numbering)
Interfaces
RS232C 1,200 to 230,400 baud/8 bit
USB 2.0 Hi-Speed device to connect a PC
Ethernet 10/100 Mbit/s	LPD, RawIP printing, SOAP webservice, OPC UA, WebDAV, DHCP, HTTP/HTTPS, FTP/FTPS, TIME, NTP, Zeroconf, SNMP, SMTP, VNC
1 x USB host on the operation panel for 1 x USB host on the operation panel for	Service Key or USB memory stick USB WLAN stick 2.4 GHz 802.11b/g/n
2 x USB host on the back of the device for	Service Key, USB memory stick, keyboard, barcode scanner, USB Bluetooth adapter, USB WLAN stick, external operation panel
USB WLAN stick 2.4 GHz 802.11b/g/n	hotspot mode or infrastructure mode (enclosed in the scope of delivery)
USB WLAN stick 2.4 GHz 802.11b/g/n + 5 GHz 802.11a/n/ac, rod antenna	hotspot mode or infrastructure mode
USB Bluetooth adapter
Periphery connection USB host, 24 VDC
Digital I/O interface with 8 inputs and outputs
Operating data
Power supply	100 - 240 VAC, 50/60 Hz, PFC
Power consumption	Standby <10 W / typical 100 W
Temperature / humidity: Operation	+5 - 40°C / 10 - 85% not condensing
Temperature / humidity: Storage	0 - 60°C / 20 - 85% not condensing
Temperature / humidity Transport	–25 - 60°C / 20 - 85% not condensing
Approvals	CE, FCC Class A, ICES-3, cULus, CB, CoC Mexico, CCC, EAC, BIS, BSMI, KC-Mark

Technical data SQUIX with SQUIX M and SQUIX MP by comparison (PDF)

The material specifications are standard values. Applications with small labels, thin, slim, thick and stiff materials as well as strongly adherent labels have to be tested.
in cases of tearing off, cutting, rewinding
The ribbon should at least correspond with the width of the liner material.

Want to learn more?

Label printers SQUIX

Ask for an offer free of charge and without obligation:

Request a quote

Learn more:

Read the product brochure (PDF)

An overview of which accessories are compatible with which device version and which accessories can be adopted from the A + series you can find in the product brochure.

expand all collapse all

Extra equipment

Print roller DRS4

to process materials up to 120 mm wide

Silicone coating for extra long service life at a higher print image tolerance
External operation panel

If the operation panel on a printer cannot be accessed after installation, an additional external one can be plugged.

Printer connection: USB 2.0 Hi-speed device

Connecting cables are required for power supply. The following or equivalent cables ensure functionality.

Connecting USB cable, length 1.8 m
Connecting USB cable, length 3 m
Connecting USB cable, length 5 m
Connecting USB cable, length 11 m
Connecting USB cable, length 16 m
Antistatic brush

to dissipate electrostatic charge after printing, in particular if plastic materials are in use
Adapter 100

to process label rolls having a core diameter of 100 mm and outside diameters succeeding 180 mm
SD memory card
USB memory stick
USB WLAN stick

2.4 GHz 802.11b/g/n + 5 GHz 802.11a/n/ac

A rod antenna provides extended ranges in infrastructure mode.
USB Bluetooth adapter

Scanner CC200-SQ

to detect linear barcodes and 2D codes

A camera checks a barcode printed on a label in horizontal or vertical direction in terms of legibility or content. In the case of a bad encoding, printing stops and the label is removed.

The scanner operates in tear-off mode or peel-off mode.

For further information see assembly instructions: www.cab.de/en/cc200

Scanner	CC200-SQ
To be used with	all SQUIX printers
Scan distance mm	45 - 150
Scan angle °	-15 to +15
Number of barcodes on a label	1
Controls GOODBAD	legibility
Controls VERIFY	results in terms of legibility are compared with initial data

Label peel-off
- Present sensor PS800

  for use with materials guided left-aligned

  Labels in peel-off position are detected. After a label has been removed, the next one is printed automatically.

  Label widths from 16 mm
  Label heights from 6 mm
  7 mm distant from locating edge
- Present sensor PS900

  for use with materials guided left-aligned or centered

  The moveable sensor in particular qualifies for detecting small or customized labels. After a label has been removed, the next one is printed automatically.

  Label widths from 4 mm
  Label heights from 6 mm
  Left-aligned: 12 - 60 mm distant from locating edge
  centered: position ibid.
- Extended peel-off plate DP410

  to process labels that hardly separate from their liner due to a strong adhesive or very thick liner material. Use only if printing on demand has been triggered by the touch of a button or by a control signal. A present sensor cannot be used.
- Reflective product sensor

  to detect products automatically on a conveyor

Interfaces, switches
- Digital I/O interface

  Labeling is triggered by a PLC, a sensor or with the help of a hand switch. Status and error reports are displayed.
- I/O interface plug, SUB-D, 25 pins

  Clamping screws are provided to plug all the control signals to the I/O interface.
- Label selection - I/O box

  16 labels per box can be selected from a memory card by a superior control unit such as a PLC. Two boxes may be plugged. Using an I/O box, four inputs and outputs suffice to implement simple PLC processes via abc programming.
- Hand switch TR2

  to plug to the digital I/O interface
- Foot switch

  to plug to the digital I/O interface

Connecting cable
- Connecting RS232-C cable

  9/9 pin, length 3 m

Cutting, perforating, stacking

Cutter CU

Cutter CU
to cut paper labels, self-adhesive labels, cardboard, textile and plastic materials, as well as shrink tubes.

Tray to collect a maximum of approx. 50 labels

Cutter	CU200	CU400		CU600
To be used with	SQUIX 2	SQUIX 4.3 SQUIX 4	SQUIX 4.3 M SQUIX 4 M SQUIX 4.3 MT SQUIX 4 MT	SQUIX 6.3
Material: Width up to mm	67	120	114	180
Material: Weight cardboard gr/m²	60-300
Material: Thickness mm	0.05-1.1
Cut length from mm	5
Material passage up to mm	2.5
Cycle performance cuts/min with material 1 mm high, no backfeed	100
Stop printing if	cutter has not reached final position
Tray
Label height up to mm	-	100		-

Perforation cutters PCU400

perforate continuous materials such as textile tapes or shrink tubes to simplify separation by hand. Cutting the material is also possible.

Perforation cutter	PCU400/2,5	PCU400/10
To be used with	SQUIX 4.3, SQUIX 4, SQUIX 4.3 M, SQUIX 4 M, SQUIX 4.3 MT, SQUIX 4 MT
Perforating: Web spacing mm	2.5	10
Perforating: Web width mm	0.5
Material: Width up to mm	85
Material: Weight cardboard gr/m²	60 - 300
Material: Thickness mm	0.05 - 1.1
Cutting length from mm	5
Material passage from mm	2.5
Cycle performance cuts/min with material 1 mm high, no backfeed	100
Stop printing if	cutter has not reached final position

Stacker ST400 M providing a cutter

Only for label printers "M" with centered material guidance

1 Printed materials are cut and collected. As soon as stacking has reached its maximum height , printing interrupts. Limitations may occur with stiff or curved materials. We recommend to have such applications tested by cab.

2 Devices can be set anywhere on a table with the help of a base frame.

Stacker providing a cutter	ST400 M
To be used with	SQUIX 4.3 M, SQUIX 4 M, SQUIX 4.3 MT, SQUIX 4 MT
Material Width mm	20 - 100
Material Weight cardboard gr/m²	60 - 300
Material Thickness mm	0.05 - 0.8
Cut length mm	20 - 150
Material passage up to mm	1.2
Cycle performance cuts/min with material 1 mm high, no backfeed	100
Stop print job when	cutter has not reached final position, paper jam, stacker cover open, stacking has reached maximum height
Stacking height up to mm	100

Support table - label W x H
The table and the protective cover adapt to the label size. To be requested individually

Cutter CSQ 400

provided for all basic SQUIX 4 devices

assembled to a printer (see delivery program Pos. 1.12/13) or accessorial on delivery.

Paper labels and self-adhesive labels, cardboard and plastic materials, as well as shrink tubes can be cut. By pivoting the cutter, materials can be accessed to be removed. Label heights can be set on the tray.

By keeping in memory the number of cuts, wear can be controlled.

The CSQ 402 provides a more powerful engine and titanium-coated cutters. These guarantee highly performant cutting even through thick materials such as cardboard and shrink tubes, as well as through self-adhesive materials.

Cutter	CSQ 401	CSQ 402
To be used with	all basic SQUIX 4 devices
Material Width up to mm	120	120
Material: Weight of cardboard gr/m²	200	300
Materia:l Thickness mm	0.7	1.1
Cut length from mm	10	10
Tray to collect material lengths up to mm	100	100
Material passage up to mm	2.5	2.5
Cycle performance cuts/min with material 1 mm high, no backfeed	120	200
Service life motor no. of cuts up to	2 mio.	5 mio.
Service life cutter no. of cuts up to	1* mio.	2* mio.
Controls	cutter has not reached final position, cutter pivoted, cover removed from cutter

*depending from the material

Rewinding, unwinding

with or without the use of a cardboard core

Guide plates RG

Guide plates RG enable labels to be rewound internally on peel-off printers.
The peel-off plate is therefore replaced by a guide plate.

Guide plate	RG200	RG400
To be used with	SQUIX 2 P	SQUIX 4.3 P SQUIX 4 P	SQUIX 4.3 MP SQUIX 4 MP
Material width up to mm	67	120	114
Roll diameter up to mm	142
Tightening axle for core diameters of mm	38.1 - 40
Winding	outside

External rewinders ER1, ER2 to plug directly to a printer using screws

They pick up materials wound either on the outside or on the inside. An electronic swing arm keeps winding consistent and tight.

External rewinder	ER1/210	ER2/210
To be used with	SQUIX 4.3 SQUIX 4, SQUIX 4.3 M SQUIX 4 M	SQUIX 6.3
Material width up to mm	120	180
Roll diamater up to mm	205
Tightening axle for core diameters of mm	76
Winding	outside or inside

External rewinders ER4, ER6 providing a built-in power supply unit

They operate also with printers other than cab. They pick up materials wound either on the outside or on the inside. An electronic swing arm keeps winding consistent and tight.

External rewinder	ER4/300	ER6/300
To be used with	SQUIX 4.3 SQUIX 4 SQUIX 4.3 M SQUIX 4 M	SQUIX 6.3
Material width up to mm	120	180
Roll diameter up to mm	300
Tightening axle for core diameters of mm	76
Winding	outside or inside
6.7 Adapter kit for
ER4, ER6 with SQUIX
ER4, ER6 and EU4, EU6 with SQUIX

External unwinders EU

enable labels to be fed consistent even if rolls are heavy.
They pick up materials wound either on the outside or on the inside.

External unwinder	EU4/300		EU6/300
To be used with	SQUIX 4.3 SQUIX 4	SQUIX 4.3 M SQUIX 4 M SQUIX 4.3 MT SQUIX 4 MT	SQUIX 6.3
Material width up to mm	120	114	180
Roll diameter up to mm	300
Core diameter up to mm	38.1
Core diameter adapter included mm	76
Winding	outside or inside
6.7 Adapter kit for
EU4, EU6 to a SQUIX printer
ER4, ER6 and EU4, EU6 to a SQUIX printer

Applicators and dispensing module

Applicator S1000

Labeling in real time
A S1000 assembled to a SQUIX peel-off printer provides a cost-effective solution if operated semi-automatically or integrated in vertical orientation in production lines. A stroke cylinder applies the labels to products.

1 Long service life: The ball bearing guide bars are low-wear.

2 Products of different heights: can be labeled by means of a stroke cylinder. Various stroke lengths are provided.

3 Compressed air regulation unit: Micro filters prevent from contamination. Regulating the pressure ensures a permanent good labeling quality.

4 Highly-reliable processes: The supporting air, intake air and stroke speed may be adapted. If sensitive products and packagings are in use, the pressing force can be reduced to less than 10N (1 kg). To prevent intake ducts from contamination, they get purged after any labeling.

5 Label sizes: Labels 25 to 176 mm wide and 25 to 200 mm high can be applied.

6 Supporting air: to blow labels onto a pad

7 Pad: Labels are transferred to a pad and held there by vacuum. They move towards a product uby means of a stroke cylinder.

Pre-dispense button
to verify a labeling process. By pushing the button once, a label is printed and transferred to the applicator. By pushing the button once more, labeling is triggered.

Applicator	S1000-220	S1000-300	S1000-400
To be used with	SQUIX 2, SQUIX 4.3, SQUIX 4, SQUIX 4.3 M, SQUIX 4 M, SQUIX 6.3
Cylinder stroke mm	220	300	400
Pad stroke below the device mm	64	144	244
Compressed air bar	4.5
Cycle rate labels/min approx.¹⁾	25

1) calculated at a stroke of 100 mm below the device, with labels 100 mm high, at a print speed of 100 mm/s

Universal pads

Drilled intake holes are arranged in a grid and covered by foil, to be pierced according to the size of a label.

Universal pad	A1021		A1021
To be used with	SQUIX 2	SQUIX 4.3 SQUIX 4	SQUIX 4.3 SQUIX 4
Label width mm	25 - 63	25 - 70	25 - 90
Label height mm	25 - 60		25 - 90
Product surface	flat
Product height	various
State of a product during labeling	at rest

Tamp pads

are manufactured according to the size of a label.

Tamp pad	A1021
To be used with	SQUIX 2	SQUIX 4.3 SQUIX 4	SQUIX 6.3
Label width mm	25-63	25-116	50-176
Label height mm	25-200
Product surface	flat
Product height	various
State of a product during labeling	at rest

Universal pads spring-mounted, tamp pads spring-mounted

Universal pads, spring-mounted
Pitch of spring enables labels to apply even on inclined surfaces. Drilled intake holes are arranged in a grid and covered by foil, to be pierced according to the size of a label.

Tamp pads, spring-mounted
Pitch of spring enables labels to apply even on inclined surfaces. Manufacture according to the size of a label

	Universal pad		Tamp pad
	A1321	A1321	A1321
To be used with	SQUIX 4.3, SQUIX 4	SQUIX 4.3, SQUIX 4	SQUIX 4.3, SQUIX 4	SQUIX 6.3
Label width mm	25 - 116	25 - 116	25 -1 16	50 - 176
Label height mm	25 - 102	25 - 152	25 - 200
Product surface	flat
Product height	various
State of a product during labeling	at rest

Blow pads

to apply labels on products sensitive to pressure. A pad moves to a height fixed approx. 10 mm above a product to trigger labeling.

Blow pad	A2021
To be used with	SQUIX 2	SQUIX 4.3, SQUIX 4	SQUIX 6.3
Label width mm	25 - 63	25 - 116	provided on request
Label height mm	25-100		provided on request
Product surface	flat
Product height	fixed
State of a product during labeling	at rest or in motion

Roll-on pads

Labels are fed to the roller of a pad during printing. The pad then moves to the product. Labels are picked up by the product in motion and rolled on.

Roll-on pad	A1411
To be used with	SQUIX 4.3, SQUIX 4	SQUIX 6.3
Label width mm	25 - 116	50 - 176
Label height mm	80 - 200
Product surface	flat
Product height	various
State of a product during labeling	in motion

Applicator S3200

Labeling in real time
A S3200 assembled to a SQUIX peel-off printer provides a cost-effective solution if operated semi-automatically or integrated in production lines. Printed labels are applied to products automatically. For this purpose, labels are set 45° to 95° to the horizontal by a rotary cylinder and move towards products by means of a a short-stroke cylinder.

In terms of service life, pre-dispense, compressed air regulation, process reliability and supporting air, data correspond to the S1000 applicator

Applicator	S3200
To be used with	SQUIX 2, SQUIX 4.3, SQUIX 4, SQUIX 4.3 M, SQUIX 4 M
Rotary cylinder	45°- 90°
Stroke cylinder up to mm	30
Immersion depth pad F up to mm	5
Compressed air bar	4.5
Cycle rate labels/min approx.¹⁾	20

calculated with labels 40 mm high, at a print speed of 100 mm/s

Tamp pads or blow pads are manufactured according to the label size.

Tamp pad	A3200-1100
To be used with	SQUIX 2	SQUIX 4.3, SQUIX 4
Label width mm	4 - 63	10 - 116
Label height mm	6 - 80
Product surface	flat
State of a product during labeling	at rest

Blow pad	A3200-2100
To be used with	SQUIX 2	SQUIX 4.3, SQUIX 4
Label width mm	10 - 63	10 - 116
Label height mm	10 - 80
Product surface	flat
State of a product during labeling	at rest or in motion

Demand modules S5104, S5106

label products in motion on a conveyor. Positions are detected by a product sensor. As soon as peel-off has been triggered, the next label is printed. The speed of a product on the conveyor must adapt to the print speed. A reflective sensor detects positions.

Demand module	S5104	S5106
To be used with	SQUIX 4.3, SQUIX 4	SQUIX 6.3
Label width mm	25 - 116	50 - 176
Label height mm	25 - 210
Print line distance to the peel-off plate mm	336- 518
Product surface	flat
Product height	fixed
State of a product during labeling	in motion, speed adapted to the printer
Cycle rate labels/min approx.¹⁾	60

calculated with labels 100 mm high, at a print speed of 100 mm/s

All-around labeler

to label cylindric items on a 360° circumference. Products are laid onto the rollers and labeling is triggered via a hand switch or a foot switch. Delivery includes a mount, a cable to connect to a SQUIX printer, and a foot switch

Tamp pad	A1021	M1021
To be used with	SQUIX 2	SQUIX 4.3, SQUIX 4
Label width mm	25 - 63	25 - 116
Label height mm	25 - 140
Product diameter mm	12 - 40
Product surface	cylindric
State of a product during labeling	in rotary motion

Assembly aids

provided for SQUIX label printers
Mounting foot

Mount
to assemble a labeling system and a product retainer

1 Mounting plate: to assemble a labeling system

2 Profile: aluminum square: 40, 80, 120 mm; further lengths may be provided on request

3 Base plate: to assemble a product retainer, 500 x 255 mm standard size

Floor stand and Printer retainer

Floor stand
to enable a printer operate quickly and flexibly in any production line. Positions (i.e. heights, widths) on which products need to be labelled can be set in few steps. Four guide rollers on the carriage provide mobility. To be aligned on site using adjustable feet

Floor stand	1600
Total height mm	1,600
Labeling height up to mm	1,400
Outreach to centre of label mm	230 - 500
Carriage dimensions W x H x D mm	600 x 140 x 860

Printer retainer
to fix and quick-lock a label printer

Label printers with special covers or protection chassis
- Printers providing a conductive ESD surface

  available for all printer types

  All the parts of a casing are manufactured according to DIN EN 61340-5-1:2016 to protect from electrostatic charge.

  Surface resistant according to DIN IEC 60093 ≤ 104 ohm; charge reduces from 1,000 V to 100 V in less than two seconds

  The hinged cover with the upper device plate (as a unit) are provided as a spare part.
- Printers for use in food applications

  available for all printer types

  Covers are magnetic so that splindered parts can be detected by metal detectors or x-ray inspection systems.

  Blue color serves for optical differentiation from food.

  The entire casing may be manufactured detectable on request.

  The materials manufactured comply with food regulations such as EU Nr. 10/2011 and FDA CFR 21 177.2600.
- Stainless steel chassis to protect in food applications

  available for SQUIX 4 and SQUIX 6 printers

  Labels are removed through the front.

  FThe front has to be opened and the printer pulled out on telescopic rails to replace materials. Close the front for steam jet cleaning.

  Protection class IP69K according to EN 60529
- Chassis to protect from dust

  available for SQUIX 4 and SQUIX 6 printers

  Labels are removed through the front.

  The fan with a filter provide overpressure and prevent from dust entering the chassis.

  Protection class IP52 according to EN 60529

  Chassis providing a suction nozzle to protect in cleanroom applications
  available for SQUIX 4 and SQUIX 6 printers

Software
- Label software cablabel S3

  In cablabel S3 cab concentrates label design, print control and monitoring of all cab marking systems and synchronizes the development of devices and software.

  More information to cablabel S3

Want to learn more?

Label printers SQUIX

Ask for an offer free of charge and without obligation:

Request a quote

Learn more:

Read the product brochure (PDF)

Video: Label printers SQUIX - designed for industrial application

Other formats: Label printer SQUIX - designed for industrial application (MPEG-4; 218 MB)

SQUIX case studies

Play

Formula Student: SQUIX dynamically imprints names on acetate silk
Read case study

Play

20 years united by wine labeling: Vier Jahreszeiten winegrowers and cab
Read case study

cab Video Tutorials SQUIX

Play

SQUIX Base version: Loading labels

Play

SQUIX: Loading leporello

Play

SQUIX Base version: Loading ribbon

Play

SQUIX: Cleaning printhead

Play

SQUIX: Cleaning print roller

Play

SQUIX: Changing print roller

Play

SQUIX Dispensing version: Rewind labels internally

Play

SQUIX Dispensing version: Remove internally wound labels

Play

SQUIX Dispensing version: Dispensing labels

Play

SQUIX Dispensing version : Changing dispense plate

Play

SQUIX: Install WLAN stick

Want to learn more?

Label printers SQUIX

Ask for an offer free of charge and without obligation:

Request a quote

Learn more:

Read the product brochure (PDF)

Documentation

expand all collapse all

Catalogs

Title	Format	Version	Last change	Language
SQUIX	PDF - 6.12 MB	06/2021	31/05/2021	English
Overview Product Marking	PDF - 5.55 MB	06/2021	31/05/2021	English

Operation Manuals

Title	Format	Version	Last change	Language
Operator's Manual SQUIX	PDF - 3.27 MB	09/2020	27/11/2020	English

Other languages

Title	Format	Version	Last change	Language
Инструкция за експлоатация на принтер за етикети SQUIX	PDF - 3.33 MB	09/2020	25/11/2020	Български
操作手冊條碼打印機 SQUIX	PDF - 3.75 MB	09/2020	26/11/2020	简体字
操作手冊條碼印表機 SQUIX	PDF - 4.01 MB	09/2020	26/11/2020	繁體字
Upute za upotrebu pisača za etikete SQUIX	PDF - 3.29 MB	09/2020	26/11/2020	Hrvatski
Návod k obsluze tiskárny etiket SQUIX	PDF - 3.30 MB	09/2020	25/11/2020	Čeština
Betjeningsvejledning til etiketprinteren SQUIX	PDF - 3.25 MB	09/2020	26/11/2020	Dansk
Gebruiksaanwijzing etikettenprinter SQUIX	PDF - 3.26 MB	09/2020	26/11/2020	Nederlands
Etiketiprinteri SQUIX kasutusjuhend	PDF - 3.25 MB	09/2020	26/11/2020	Eesti
Käyttöohje etikettitulostin SQUIX	PDF - 3.22 MB	09/2020	25/11/2020	Suomi
Οδηγίες χρήσης εκτυπωτή ετικετών SQUIX	PDF - 3.33 MB	09/2020	25/11/2020	ελληνικά
Kezelési útmutató Címkenyomtató SQUIX	PDF - 3.30 MB	09/2020	26/11/2020	Magyar
ラベルプリンターSQUIX取扱説明書	PDF - 3.83 MB	09/2020	25/11/2020	日本語
SQUIX 라벨 프린터 사용 설명서	PDF - 3.46 MB	09/2020	25/11/2020	한국어
Lietošanas pamācība Etiķešu printeris SQUIX	PDF - 3.30 MB	09/2020	25/11/2020	Latviešu
Etikečių spausdintuvo SQUIX naudojimo instrukcija	PDF - 3.30 MB	09/2020	25/11/2020	Lietuvių
Bruksanvisning etikettskriver SQUIX	PDF - 3.25 MB	09/2020	26/11/2020	Norsk
Instrukcja obsługi drukarki etykiet SQUIX	PDF - 3.31 MB	09/2020	25/11/2020	Polski
Manual de instruções da impressora de etiquetas SQUIX	PDF - 3.29 MB	09/2020	25/11/2020	Português
Instrucţiuni de utilizare imprimantă pentru etichete SQUIX	PDF - 3.29 MB	09/2020	26/11/2020	Română
Руководство по эксплуатации принтера этикеток SQUIX	PDF - 3.33 MB	09/2020	26/11/2020	Pусский
Návod na obsluhu tlačiarne štítkov SQUIX	PDF - 3.30 MB	09/2020	26/11/2020	Slovenský
Betriebsanleitung SQUIX	PDF - 3.26 MB	09/2020	27/11/2020	Deutsch
Istruzioni per l’uso SQUIX	PDF - 3.28 MB	09/2020	27/11/2020	Italiano
Manuel d'utilisation SQUIX	PDF - 3.27 MB	09/2020	27/11/2020	Français
Navodila za uporabo tiskalnika etiket SQUIX	PDF - 3.29 MB	09/2020	25/11/2020	Slovenščina
Instrucciones de uso de la impresora de etiquetas SQUIX	PDF - 3.28 MB	09/2020	25/11/2020	Español
Bruksanvisning Etikettskrivare SQUIX	PDF - 3.25 MB	09/2020	25/11/2020	Svensk
คู่มือการใช้งานเครื่องพิมพ์ฉลาก SQUIX	PDF - 3.30 MB	09/2020	25/11/2020	ภาษาไทย
Kullanım Kılavuzu Etiket Yazıcısı SQUIX	PDF - 3.30 MB	09/2020	26/11/2020	Türkçe

EU Declaration of Conformity

Title	Format	Version	Last change	Language
EU Declaration of Conformity SQUIX	PDF - 36 KB	10/2019	26/11/2020	English

Other languages

Title	Format	Version	Last change	Language
ЕС декларация за съответствие SQUIX	PDF - 80 KB	10/2019	26/11/2020	Български
EU izjava o sukladnosti SQUIX	PDF - 77 KB	10/2019	26/11/2020	Hrvatski
EU prohlášení o shodě SQUIX	PDF - 78 KB	10/2019	26/11/2020	Čeština
EU-overensstemmelseserklæring SQUIX	PDF - 36 KB	10/2019	26/11/2020	Dansk
EU-conformiteitsverklaring SQUIX	PDF - 36 KB	10/2019	26/11/2020	Nederlands
ELi vastavusdeklaratsioon SQUIX	PDF - 36 KB	10/2019	26/11/2020	Eesti
EU-vaatimustenmukaisuusvakuutus SQUIX	PDF - 36 KB	10/2019	26/11/2020	Suomi
Déclaration UE de conformité SQUIX	PDF - 38 KB	10/2019	26/11/2020	Français
Δήλωση συμμόρφωσης ΕΕ SQUIX	PDF - 77 KB	10/2019	26/11/2020	ελληνικά
EU-megfelelőségi nyilatkozat SQUIX	PDF - 75 KB	10/2019	26/11/2020	Magyar
ES atbilstības deklarācija SQUIX	PDF - 83 KB	10/2019	26/11/2020	Latviešu
ES atitikties deklaracija SQUIX	PDF - 78 KB	10/2019	27/11/2020	Lietuvių
EU-samsvarserklæring SQUIX	PDF - 36 KB	10/2019	26/11/2020	Norsk
Deklaracja zgodności UE SQUIX	PDF - 78 KB	10/2019	26/11/2020	Polski
Declaração UE de conformidade SQUIX	PDF - 36 KB	10/2019	26/11/2020	Português
Declarația UE de conformitate SQUIX	PDF - 77 KB	10/2019	26/11/2020	Română
Декларация соответствия требованиям ЕС SQUIX	PDF - 82 KB	10/2019	26/11/2020	Pусский
EÚ vyhlásenie o zhode SQUIX	PDF - 77 KB	10/2019	26/11/2020	Slovenský
Izjava EU o skladnosti SQUIX	PDF - 78 KB	10/2019	26/11/2020	Slovenščina
EU-försäkran om överensstämmelse SQUIX	PDF - 36 KB	10/2019	26/11/2020	Svensk
AB-Uyumluluk Bildirimi SQUIX	PDF - 80 KB	10/2019	26/11/2020	Türkçe
Dichiarazione di conformità UE SQUIX	PDF - 32 KB	04/2017	27/11/2020	Italiano
EU-Konformitätserklärung SQUIX	PDF - 32 KB	10/2019	26/11/2020	Deutsch

Interface Descriptions

Title	Format	Version	Last change	Language
Interface Description I/O 24V25-1 24 V, SUB-D25, 8 inputs, 8 outputs	PDF - 334 KB	05/2020	03/12/2020	English

Other languages

Title	Format	Version	Last change	Language
Schnittstellenbeschreibung I/O 24V25-1 24 V, SUB-D25, 8 Eingänge, 8 Ausgänge	PDF - 324 KB	05/2020	03/12/2020	Deutsch

Configuration Manuals

Title	Format	Version	Last change	Language
Configuration manual cab Label Printers from SN 14089	PDF - 2.20 MB	05/2021	06/05/2021	English
Configuration manual SQUIX up to SN 14088	PDF - 1.64 MB	08/2017	03/12/2020	English

Other languages

Title	Format	Version	Last change	Language
Konfigurationsanleitung cab Etikettendrucker ab SN 14089	PDF - 2.23 MB	05/2021	06/05/2021	Deutsch
Konfigurationsanleitung SQUIX bis SN 14088	PDF - 1.61 MB	08/2017	03/12/2020	Deutsch
Manuel de configuration imprimantes d'étiquettes cab à partir du numéro de série 0014089	PDF - 2.31 MB	05/2021	07/05/2021	Français

Programming

Title	Format	Version	Last change	Language
Programming Manual JScript X4 for SQUIX, MACH 4S, EOS2, EOS5, HERMES Q	PDF - 10.26 MB	9.4 - 5.33	02/02/2021	English
cabPROTECT - Data security in label printing	PDF - 1.53 MB	05/2021	31/05/2021	English
Networked labeling with OPC UA cab and the Smart Factory	PDF - 1.12 MB	03/2019	28/01/2021	English
PLC Programmer's Guide HERMES Q, SQUIX, PX Q with label layouts and programming examples	ZIP - 16.17 MB	06/2020	03/12/2020	English

Other languages

Title	Format	Version	Last change	Language
cab Download Converter (download.exe) Converts image, font and database files into the JScript download data format. Install MS Visual C++ 2010 Redistributable if not available on your system.	ZIP - 9 KB	2.3	15/12/2020	–
Marquage en réseau avec OPC UA cab et l'usine intelligente	PDF - 3.69 MB	08/2019	02/12/2020	Français
Programmieranleitung JScript für SQUIX, MACH 4S, EOS2/EOS5, HERMES Q und PX Q	PDF - 9.94 MB	9.4 - 5.33	02/12/2020	Deutsch
SPS Programmieranleitung HERMES Q, SQUIX, PX Q mit Etikettenlayouts und Beispielprogrammen	ZIP - 16.22 MB	06/2020	03/12/2020	Deutsch
Vernetzt kennzeichnen mit OPC UA cab und die intelligente Fabrik	PDF - 1.13 MB	03/2019	28/01/2021	Deutsch

Service Manuals

Title	Format	Version	Last change	Language
Service Manual SQUIX	PDF - 2.27 MB	09/2020	18/02/2021	English

Other languages

Title	Format	Version	Last change	Language
Serviceanleitung SQUIX	PDF - 2.27 MB	09/2020	02/12/2020	Deutsch

Spare Parts

Title	Format	Version	Last change	Language
Spare Parts List SQUIX 2	PDF - 1.05 MB	10/2020	03/12/2020	English
Spare Parts List SQUIX 4	PDF - 1.64 MB	10/2020	03/12/2020	English
Spare Parts List SQUIX 6.3	PDF - 1.08 MB	10/2020	03/12/2020	English

Other languages

Title	Format	Version	Last change	Language
Ersatzteilliste SQUIX 2	PDF - 1.05 MB	10/2020	03/12/2020	Deutsch
Ersatzteilliste SQUIX 4	PDF - 1.64 MB	10/2020	03/12/2020	Deutsch
Ersatzteilliste SQUIX 6.3	PDF - 1.08 MB	10/2020	03/12/2020	Deutsch

cab Video Tutorials

Title	Format	Version	Last change	Language
How to insert labels in SQUIX label printers (base version)?	–	–	19/12/2018	–
How to insert leporello in SQUIX label printers?	–	–	02/08/2018	–
How to insert ribbon in SQUIX label printers (base version)?	–	–	19/12/2018	–
How to clean print head at SQUIX label printers?	–	–	19/12/2018	–
How to clean print roller at SQUIX label printer?	–	–	19/12/2018	–
How to change the print roller at SQUIX label printer?	–	–	19/12/2018	–
How to rewind labels internally with SQUIX peel-off version?	–	–	19/12/2018	–
How to remove internally wound labels at SQUIX peel-off version?	–	–	19/12/2018	–
How to insert labels in SQUIX label printers (peel-off version)?	–	–	19/12/2018	–
How to change the dispense plate at SQUIX label printers?	–	–	19/12/2018	–
How to install wlan stick at SQUIX label printers?	–	–	19/12/2018	–

Feed Path Schemes

Title	Format	Version	Last change	Language
Feed Path Scheme SQUIX 2 The several layers of the PDF may be activated selectively before printing. That allows to adapt the schemes to the application.	PDF - 217 KB	11/2018	03/12/2020	English
Feed Path Scheme SQUIX 4 The several layers of the PDF may be activated selectively before printing. That allows to adapt the schemes to the application.	PDF - 486 KB	11/2018	03/12/2020	English
Feed Path Scheme SQUIX 6.3 The several layers of the PDF may be activated selectively before printing. That allows to adapt the schemes to the application.	PDF - 222 KB	11/2018	03/12/2020	English

Other languages

Title	Format	Version	Last change	Language
Einlegeschema SQUIX 2 Vor dem Druck können die verschiedenen Ebenen in der PDF wahlweise aktiviert werden. Dies ermöglicht die Anpassung der Schemas an den konkreten Einsatzfall.	PDF - 212 KB	11/2018	03/12/2020	Deutsch
Einlegeschema SQUIX 4 Vor dem Druck können die verschiedenen Ebenen in der PDF wahlweise aktiviert werden. Dies ermöglicht die Anpassung der Schemas an den konkreten Einsatzfall.	PDF - 477 KB	11/2018	03/12/2020	Deutsch
Einlegeschema SQUIX 6.3 Vor dem Druck können die verschiedenen Ebenen in der PDF wahlweise aktiviert werden. Dies ermöglicht die Anpassung der Schemas an den konkreten Einsatzfall.	PDF - 211 KB	11/2018	03/12/2020	Deutsch
Schémas de mise en place des consommables SQUIX 2 Sélectionnez le type de consommables pour obtenir le schéma de mise en place correspondant	PDF - 213 KB	11/2018	03/12/2020	Français
Schémas de mise en place des consommables SQUIX 4 Sélectionnez le type de consommables pour obtenir le schéma de mise en place correspondant	PDF - 496 KB	11/2018	03/12/2020	Français
Schémas de mise en place des consommables SQUIX 6.3 Sélectionnez le type de consommables pour obtenir le schéma de mise en place correspondant	PDF - 222 KB	11/2018	03/12/2020	Français

Manuals Accessories

Title	Format	Version	Last change	Language
Present Sensor PS800 / PS900 / PS1000 - Operator's Manual	PDF - 259 KB	09/2017	03/12/2020	English
Cutter CU200 / CU400 / CU600 - Instructions	PDF - 833 KB	01/2021	20/01/2021	English
Cutter CSQ401 / CSQ402 - Assembly Instructions	PDF - 1.53 MB	03/2021	24/03/2021	English
Perforation Cutter PCU400 - Operator's Manual	PDF - 848 KB	10/2016	03/12/2020	English
Stacker with Cutter ST400 - Operator's Manual	PDF - 1.18 MB	02/2017	03/12/2020	English
Code Checker CC100 - Operator's Manual	PDF - 546 KB	04/2017	03/12/2020	English
Label File Selection Box - Input Output Box - Assembly Instructions	PDF - 194 KB	05/2020	02/12/2020	English
External Rewinder ER4, ER6, ER8 - Operator's Manual	PDF - 955 KB	10/2017	03/12/2020	English
Antistatic Brush - Assembly Instruction	PDF - 86 KB	06/2020	08/06/2020	English
Adapter Kit - Mounting Instructions	PDF - 532 KB	10/2017	03/12/2020	English
External Operation Panel - Assembly Instructions	PDF - 138 KB	07/2019	02/12/2020	English
Scanner CC200-SQ - Assembly Instructions	PDF - 904 KB	01/2020	03/12/2020	English

Other languages

Title	Format	Version	Last change	Language
Ableitbürste - Montageanleitung	PDF - 92 KB	06/2020	03/12/2020	Deutsch
Barcodeprüfgerät CC100 - Bedienungsanleitung	PDF - 547 KB	04/2017	03/12/2020	Deutsch
Enrouleurs externes autonomes ER4, ER6 et ER8	PDF - 961 KB	10/2017	17/02/2021	Français
Etikettenauswahlbox - Ein-/Ausgabebox - Montageanleitung	PDF - 170 KB	05/2020	02/12/2020	Deutsch
Externer Aufwickler ER4, ER6, ER8 - Bedienungsanleitung	PDF - 956 KB	10/2017	03/12/2020	Deutsch
Externes Bedienfeld - Montageanleitung	PDF - 114 KB	07/2019	02/12/2020	Deutsch
Interfaces de pré-décollement PS800 / PS900 / PS1000	PDF - 284 KB	09/2017	03/12/2020	Français
Labelbox - I/O Box	PDF - 190 KB	05/2020	02/12/2020	Français
Massicot avec empileur ST400	PDF - 1.19 MB	02/2017	03/12/2020	Français
Massicot CSQ401 / CSQ402	PDF - 1.53 MB	03/2021	24/03/2021	Français
Massicot CU200 / CU400 / CU600	PDF - 868 KB	01/2021	17/02/2021	Français
Massicot de coupe et de perforation PCU400	PDF - 821 KB	10/2016	03/12/2020	Français
Panneau de commande externe	PDF - 218 KB	07/2019	18/02/2021	Français
Perforationsmesser PCU400 - Bedienungsanleitung	PDF - 854 KB	10/2016	03/12/2020	Deutsch
Scanner CC200-SQ - Montageanleitung	PDF - 931 KB	01/2020	03/12/2020	Deutsch
Schneidemesser CSQ401 / CSQ402 - Montageanleitung	PDF - 1.57 MB	03/2021	24/03/2021	Deutsch
Schneidemesser CU200 / CU400 / CU600 - Betriebsanleitung	PDF - 849 KB	01/2021	20/01/2021	Deutsch
Spendelichtschranke PS800 / PS900 / PS1000 - Bedienungsanleitung	PDF - 263 KB	09/2017	03/12/2020	Deutsch
Stapler mit Schneidemesser ST400 - Bedienungsanleitung	PDF - 1.19 MB	02/2017	03/12/2020	Deutsch
Verbindungsset Montageanleitung Verbindungsset Auf- und Abwickler zu den SQUIX-Druckern	PDF - 532 KB	10/2017	03/12/2020	Deutsch
Vérificateur de codes a barres CC100	PDF - 572 KB	04/2017	03/12/2020	Français
Vérificateur de codes a barres CC200-SQ	PDF - 455 KB	01/2020	03/12/2020	Français

EU Declarations of Conformity - Accessories

Title	Format	Version	Last change	Language
Present Sensor PS800 / PS900 / PS1000 - EU Declaration of Conformity	PDF - 30 KB	02/2017	03/12/2020	English
Cutter CU200 / CU400 / CU600 - EU Declaration of Conformity	PDF - 30 KB	07/2019	03/12/2020	English
Cutter CSQ401 / CSQ402 - EU Declaration of Conformity	PDF - 45 KB	09/2019	03/12/2020	English
Perforation Cutter PCU400 - EU Declaration of Conformity	PDF - 30 KB	07/2019	03/12/2020	English
Cutter with Stacker ST400 - EU Declaration of Conformity	PDF - 32 KB	05/2019	03/12/2020	English
Code Checker CC100 - EU Declaration of Conformity	PDF - 30 KB	04/2017	03/12/2020	English
Label File Selection Box - I/O Box - EU Declaration of Conformity	PDF - 30 KB	07/2019	02/12/2020	English
External Operation Panel - EU Declaration of Conformity	PDF - 30 KB	07/2019	02/12/2020	English
Scanner CC200-SQ - EU Declaration of Conformity	PDF - 98 KB	01/2020	03/12/2020	English

Other languages

Title	Format	Version	Last change	Language
Barcodeprüfgerät CC100 - Konformitätserklärung	PDF - 30 KB	04/2017	03/12/2020	Deutsch
Etikettenauswahlbox - Ein-/Ausgabebox - Konformitätserklärung	PDF - 30 KB	07/2019	02/12/2020	Deutsch
Externes Bedienfeld - Konformitätserklärung	PDF - 30 KB	07/2019	02/12/2020	Deutsch
Interfaces de pré-décollement PS800 / PS900 / PS1000 - Déclaration UE de conformité	PDF - 30 KB	02/2017	03/12/2020	Français
Labelbox - I/O Box - Déclaration UE de conformité	PDF - 30 KB	07/2019	02/12/2020	Français
Massicot avec empileur ST400 - Déclaration UE de conformité	PDF - 32 KB	05/2019	03/12/2020	Français
Massicot CSQ401 / CSQ402 - Déclaration UE de conformité	PDF - 45 KB	09/2019	03/12/2020	Français
Massicot CU200 / CU400 / CU600 - Déclaration UE de conformité	PDF - 32 KB	07/2019	03/12/2020	Français
Massicot de coupe et de perforation PCU400 - Déclaration UE de conformité	PDF - 32 KB	07/2019	03/12/2020	Français
Panneau de commande externe - Déclaration UE de conformité	PDF - 30 KB	07/2019	02/12/2020	Français
Perforationsmesser PCU400 - Konformitätserklärung	PDF - 31 KB	07/2019	03/12/2020	Deutsch
Scanner CC200-SQ - Konformitätserklärung	PDF - 102 KB	01/2020	03/12/2020	Deutsch
Schneidemesser CSQ401 / CSQ402 - Konformitätserklärung	PDF - 45 KB	09/2019	03/12/2020	Deutsch
Schneidemesser CU200 / CU400 / CU600 - Konformitätserklärung	PDF - 31 KB	07/2019	03/12/2020	Deutsch
Spendelichtschranke PS800 / PS900 /PS1000 - Konformitätserklärung	PDF - 30 KB	02/2017	03/12/2020	Deutsch
Stapler mit Schneidemesser ST400 - Konformitätserklärung	PDF - 32 KB	05/2019	03/12/2020	Deutsch
Vérificateur CC200-SQ - Déclaration UE de conformité	PDF - 100 KB	01/2020	03/12/2020	Français
Vérificateur de codes à barres CC100 - Déclaration UE de conformité	PDF - 30 KB	04/2017	03/12/2020	Français

Spare Parts Accessories

Title	Format	Version	Last change	Language
Cutter CU200 / CU400 / CU600 - Spare Parts List	PDF - 188 KB	01/2021	18/02/2021	English
Cutter CSQ 401 / CSQ 402 - Spare Parts List	PDF - 688 KB	11/2020	18/02/2021	English
Perforation Cutter PCU400 - Spare Parts List	PDF - 281 KB	10/2018	18/02/2021	English
Stacker with Cutter ST400 - Spare Parts List	PDF - 502 KB	10/2018	18/02/2021	English
Spare Parts List External Rewinder ER1, ER2, ER3, ER4, ER6, ER8	PDF - 1.07 MB	06/2019	18/02/2021	English

Other languages

Title	Format	Version	Last change	Language
Externer Aufwickler ER1, ER2, ER3, ER4, ER6, ER8 - Ersatzteilliste	PDF - 1.05 MB	06/2019	03/12/2020	Deutsch
Perforationsmesser PCU400 - Ersatzteilliste	PDF - 300 KB	10/2018	03/12/2020	Deutsch
Schneidemesser CSQ 401 / CSQ 402 - Ersatzteilliste	PDF - 622 KB	11/2020	03/12/2020	Deutsch
Schneidemesser CU200 / CU400 / CU600 - Ersatzteilliste	PDF - 207 KB	01/2021	18/02/2021	Deutsch
Stapler mit Schneidemesser ST400 - Ersatzteilliste	PDF - 505 KB	10/2018	03/12/2020	Deutsch

Case study

Title	Format	Version	Last change	Language
20 years united by wine labeling: Vier Jahreszeiten Winzer eG and cab	PDF - 2.96 MB	11/2018	19/11/2018	English
Formula Student Germany: SQUIX dynamically imprints names on acetate silk	PDF - 2.09 MB	10/2017	24/10/2017	English

Safety data sheets

Title	Format	Version	Last change	Language
Safety Data Sheet Special Cleaner for Glass and Plastic GR1N	PDF - 65 KB	08/2017	02/12/2020	English
Safety Data Sheet Special Rubber Cleaner WR1	PDF - 76 KB	12/2017	02/12/2020	English

Other languages

Title	Format	Version	Last change	Language
Sicherheitsdatenblatt Spezial Glasreiniger und Kunststoffreiniger GR1N	PDF - 156 KB	06/2017	02/12/2020	Deutsch
Sicherheitsdatenblatt Spezial-Gummiwalzen-Reiniger WR1	PDF - 173 KB	06/2017	02/12/2020	Deutsch

Registration is required

Please fill in the following form and ensure that you use correct email address.

You will receive an email with a confirmation link.

First name *

Last name *

email address *

cab Produkttechnik GmbH & Co KG  (hereafter "cab") or its affiliated companies hereby grants you a non-exclusive, nontransferable license at no charge to use these 3-D models and the corresponding documentation according to the following terms:
LICENSE GRANT  -  You may
- install the 3-D models on your personal computers;
- use and transmit the 3-D models on a network within a site;
- make copies of the 3-D models in machine readable form for backup purposes;
- modify the 3-D models in connection with your projects
- pass on the models to third parties in connection with your projects

LICENSE RESTRICTIONS  -  You may not:
- rent, sell, transfer or grant any rights in the 3-D models or corresponding documentation without the prior, explicit written consent of cab;
- remove any proprietary notices, labels, or marks on the 3-D models and corresponding documentation;
- make accessible to the public
- market the 3-D models as part of a product or service

NATURE OF THIS AGREEMENT  -  This license is not a sale. Provided that you pay license fees they are in consideration of the licenses granted under this Agreement. Title and copyrights to the 3-D models, corresponding documentation, and any copy made by you, remain the property of cab or its suppliers.  Failure to comply with the above restrictions shall automatically terminate this license without further notice and terminate your rights to use the 3-D models and cab shall, in addition to its other legal remedies, be entitled to its reasonable attorney fees.
LIMITED WARRANTY  - The 3-D models were compiled with great care and checked for accuracy. However cab can not guarantee that all data is up to date, correct and complete. Short-term technical changes are possible at any time. CAD software should only be used by trained staff. It is not a substitute for specialized testing and assessment. cab is not responsible for results on basis of these 3-D models. cab's entire liability and your exclusive remedy under this warranty will be, at the option of cab, to attempt to correct or help you around errors, to replace the 3-D models with functionally equivalent 3-D models, or to terminate this Agreement.
EXCEPT FOR THE ABOVE EXPRESS LIMITED WARRANTY, CAB MAKES AND YOU RECEIVE NO WARRANTIES, EXPLICIT, IMPLIED, STATUTORY OR IN ANY COMMUNICATION WITH YOU, AND CAB SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.  CAB DOES NOT WARRANT THAT THE OPERATION OF THE PROGRAM WILL BE UNINTERRUPTED OR ERROR FREE.
Some states do not allow the exclusion of implied warranties so the above exclusions may not apply to you.  This warranty gives you specific legal rights. You may also have other rights which vary from state to state.
LIMITATION OF LIABILITY  -   IN NO EVENT WILL CAB BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA, WHILE LOADING THESE 3-D MODELS OR OTHERWISE, LOST PROFITS, COST OF COVER OR OTHER SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT  DAMAGES ARISING FROM THE USE OF THE 3-D MODELS OR CORRESPONDING DOCUMENTATION, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY.  THIS LIMITATION WILL APPLY EVEN IF CAB HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Some states do not allow the limitation or exclusion of liability for incidental, or consequential damages, so the above limitation may not apply to you.
If this agreement is translated into any other language than German, the German version remains the authoritative version.
If any of the afore mentioned provisions should be or become ineffective, this does not affect the validity of the remaining provisions. The ineffective or invalid provision shall be replaced by the corresponding statutory ruling, unless the parties reach legally effective agreement on another solution. The same also applies to any loopholes in the contract.

Accept license

3D CAD models

The files are provided in STEP format, which requires CAD software. Follow this link to download a free STP Viewer:
VariCAD Viewer (External website). For downloading the CAD models you need to register. cab will handle your personal information as described in our Privacy statement. This information will not be accessible to any third party for marketing purposes. This category is under construction, more models to follow.

SQUIX 2
- SQUIX2.zip (5.41 MB)
- SQUIX2_present sensor_PS800.zip (5.85 MB)
- SQUIX2_without_frontcover.zip (4.99 MB)
SQUIX 2 with applicators
- SQUIX2_S1000-220.zip (5.78 MB)
- SQUIX2_S1000-300.zip (5.77 MB)
- SQUIX2_S1000-400.zip (5.76 MB)
- SQUIX2_S3200.zip (6.13 MB)
SQUIX 4
- SQUIX4.zip (7.02 MB)
- SQUIX4_CSQ401.zip (17.44 MB)
- SQUIX4_extended_dispense_plate.zip (7.74 MB)
- SQUIX4_PS1000.zip (12.72 MB)
- SQUIX4_PS800.zip (7.27 MB)
- SQUIX4_without_frontcover.zip (6.38 MB)
SQUIX 4 with applicators
- SQUIX4_A1000-220.zip (8.21 MB)
- SQUIX4_A1000-300.zip (8.20 MB)
- SQUIX4_A1000-400.zip (7.65 MB)
- SQUIX4_A3200.zip (8.18 MB)
- SQUIX4_S1000-220.zip (7.23 MB)
- SQUIX4_S1000-300.zip (7.22 MB)
- SQUIX4_S1000-400.zip (7.21 MB)
- SQUIX4_S3200.zip (7.36 MB)
- SQUIX4_S5104.zip (10.40 MB)
SQUIX 6
- SQUIX6.zip (6.42 MB)
- SQUIX6_CU600.zip (9.80 MB)
SQUIX 6 with applicators
- SQUIX6_S1000-220.zip (7.42 MB)
- SQUIX6_S1000-300.zip (7.41 MB)
- SQUIX6_S1000-400.zip (7.40 MB)
- SQUIX6_S5106.zip (7.25 MB)
SQUIX Accessories
- Cutter_Schneidemesser_CU400.zip (6.43 MB)
- External_operation_panel_6010186.zip (836 KB)
- External_rewinder_ER4-210.zip (328 KB)
- External_rewinder_ER4-300.zip (282 KB)
- External_unwinder_EU4.zip (1.13 MB)
- External_unwinder_EU6.zip (990 KB)
- External_unwinder_EU8.zip (818 KB)
- Floorstand_Stativ_1600_5947400.zip (519 KB)
- Mounting_plate_Montageplatte_SQUIX4_5978910.zip (137 KB)
- Present_Sensor_PS800_5977585.stp (1.12 MB)
- Printer_holder_Druckeraufnahme_SQUIX2_5979037.zip (225 KB)
- Printer_holder_Druckeraufnahme_SQUIX4_5978922.zip (152 KB)
- Printer_holder_Druckeraufnahme_SQUIX6_5979038.zip (225 KB)
- Product_sensor_25_light_barrier_5964309.zip (113 KB)
- Product_sensor_25_reflector_5917552.zip (6 KB)
- Scanner_cc200_5977840.zip (3.83 MB)
- SQUIX4_CSQ401.zip (17.44 MB)
- SQUIX4_extended_dispense_plate.zip (7.74 MB)
- SQUIX4_PS1000.zip (12.72 MB)
- SQUIX4_PS800.zip (7.27 MB)
- SQUIX6_CU600.zip (9.80 MB)

You need Adobe Reader to view the PDF-files. Download current version of Adobe Reader

Want to learn more?

Label printers SQUIX

Ask for an offer free of charge and without obligation:

Request a quote

Learn more:

Read the product brochure (PDF)

Here you can download firmware, drivers and software. Documentation on label software, printers programming and administration as well as integration of cab printers into SAP systems:
Label software

Software & Drivers

expand all collapse all

Firmware

Title	Format	Version	Last change	Language
Firmware X4 Firmware SQUIX \| EOS2 \| EOS5 \| MACH 4S \| HERMES Q \| PX Q	ZIP - 45.45 MB	5.36	10/03/2021	–
cabFirmwareUpdater Windows 32 & 64 bit (starting from Vista)	ZIP - 14.11 MB	3.9.0.0	02/02/2021	–
Release Notes Firmware X4	TXT - 59 KB	5.00 - 5.36	10/03/2021	–

Drivers

Title	Format	Version	Last change	Language
cab Linux Armv7 - 32 Bit Driver CUPS Linux Armv7 32bit Driver RPi 2/3/4 (min. CUPS 1.2)	GZ - 2.89 MB	1.42	05/10/2020	–
cab Linux x86 - 32 Bit Driver CUPS Linux Intel 32bit Driver (min. CUPS 1.2)	GZ - 2.90 MB	1.42	05/10/2020	–
cab Linux x86 - 64 Bit Driver CUPS Linux Intel/AMD 64bit Driver (min. CUPS 1.2)	GZ - 2.88 MB	1.42	05/10/2020	–
cab MAC OS X Driver Apple® Mac OS X 10.15 - 11.0	ZIP - 2.75 MB	1.42	08/12/2020	–
cab MAC OS X Driver Apple® Mac OS X 10.6 - 10.14	ZIP - 5.33 MB	1.42	05/10/2020	–
cab Windows Driver 32/64 Bit (Vista - Windows 7 - Windows 8 - Windows 8.1 - Windows 10 - Windows Server 2008, 2008 R2, 2012, 2012 R2, 2016, 2019) CERTIFIED	ZIP - 9.37 MB	5.3.03	05/10/2020	–

Software

Title	Format	Version	Last change	Language
cab Download Converter (download.exe) Converts image, font and database files into the JScript download data format. Install MS Visual C++ 2010 Redistributable if not available on your system.	ZIP - 9 KB	2.3	15/12/2020	–
cablabel S3 Demo (Free) Windows Vista, 7, 8, 10, Server 2008, 2008 R2, 2012, 2012 R2	ZIP - 51.42 MB	1.4.0.2	09/12/2020	–
cablabel S3 Lite (Free) Windows Vista, 7, 8, 10, Server 2008, 2008 R2, 2012, 2012 R2	ZIP - 61.88 MB	1.4.0.2	09/12/2020	–
cablabel S3 Print Windows Vista, 7, 8, 10, Server 2008, 2008 R2, 2012, 2012 R2	ZIP - 52.46 MB	1.4.0.2	09/12/2020	–
cablabel S3 Pro Windows Vista, 7, 8, 10, Server 2008, 2008 R2, 2012, 2012 R2	ZIP - 62.10 MB	1.4.0.2	09/12/2020	–
Database Connector Windows 32 & 64 bit	ZIP - 10.93 MB	4.3.0.1	15/12/2020	–
LogService for Database Connector	ZIP - 4.15 MB	1.7.1.0	15/12/2020	–

You need Adobe Reader to view the PDF-files. Download current version of Adobe Reader

Want to learn more?

Label printers SQUIX

Ask for an offer free of charge and without obligation:

Request a quote

Learn more:

Read the product brochure (PDF)

Lost password?

Quicklinks

Quicklinks

Label printers SQUIX Flexible printers for industrial applications

Sample applications

Label printers with left-aligned material guidance

designed for printing in different print widths on various materials

Basic device providing a tear-off plate

Peel-off device providing a rewinder internally

SQUIX label printers with centered material guide

Video: Label printer SQUIX

Label printer with left-aligned material guidance

as a peel-off device providing a rewinder internally

Operation panel

External operation panel

Print heads

Maintenance

Extra equipment

Print roller DRS4

External operation panel

Antistatic brush

Adapter 100

SD memory card

USB memory stick

USB WLAN stick

USB Bluetooth adapter

Scanner CC200-SQ

Label peel-off

Present sensor PS800

Present sensor PS900

Extended peel-off plate DP410

Reflective product sensor

Interfaces, switches

Digital I/O interface

I/O interface plug, SUB-D, 25 pins

Label selection - I/O box

Hand switch TR2

Foot switch

Connecting cable

Connecting RS232-C cable

Cutting, perforating, stacking

Cutter CU

Perforation cutters PCU400

Stacker ST400 M providing a cutter

Cutter CSQ 400

Rewinding, unwinding

Guide plates RG

External rewinders ER1, ER2 to plug directly to a printer using screws

External rewinders ER4, ER6 providing a built-in power supply unit

External unwinders EU

Applicators and dispensing module

Applicator S1000

Universal pads

Tamp pads

Universal pads spring-mounted, tamp pads spring-mounted

Blow pads

Roll-on pads

Applicator S3200

Demand modules S5104, S5106

All-around labeler

Assembly aids

Mounting foot

Floor stand and Printer retainer

Label printers with special covers or protection chassis

Printers providing a conductive ESD surface

Printers for use in food applications

Stainless steel chassis to protect in food applications

Chassis to protect from dust

Software

Label software cablabel S3

Video: Label printers SQUIX - designed for industrial application

SQUIX case studies

cab Video Tutorials SQUIX

Documentation

Catalogs

Operation Manuals

Other languages

EU Declaration of Conformity

Other languages

Interface Descriptions

Label printers SQUIX
Flexible printers for industrial applications

Basic device
providing a tear-off plate

Peel-off device
providing a rewinder internally
