Label printers SQUIX 4 MT
Particularly for textile materials

  • innovative technology
  • easy operation
  • accurate imprint
  • reliable and fast printing
  • compact, appealing design
  • highest quality standards

The SQUIX 4 MT are the further development of A4+T. The professional SQUIX label printers fit with a wide range of industrial applications. They have been developed with focus on easy and convenient operation and high reliability.

The print mechanics and the chassis are made of high-quality materials and perfectly match in terms of shape and function. A large number of peripherals and software enable customer-specific solutions.

Whether they are operated in stand-alone mode, in a PC application or within a network - the rugged SQUIX printers are always up to the mark. The high-speed processor ensures fast job processing and immediately provides the required label.

Label printers SQUIX MT series

CenteredMaterial guide
centered
with separator

SQUIX 4 MTvergrößern

The textile printer

At high heat energy the ribbon can stick with the textile tape. A roller reliably separates the material from the ribbon.

It is also possible to print on labels or continuous materials that are wound on rolls or reels.

As regards the label width, no adjustment of the plungers is needed. Width-adapted print rollers are provided for slim materials.

1.5 Label printer SQUIX 4.3 MT SQUIX 4 MT
Printable resolution dpi 300 300 600
Print speed up to mm/s 250 300 150
Print width up to mm 108.4 105.7 105.7

See also:

CenteredMaterial guide
centered

Left-alignedMaterial guide
left-aligned

SQUIX 4 M - Learn more SQUIX 4 M
especially very small labels or slim continuous materials

SQUIX 2, SQUIX 4, SQUIX 6 - Learn moreSQUIX 2, SQUIX 4, SQUIX 6
flexible printers for industrial applications in serveral widths



Video: Label printer SQUIX

for industrial applications

  View video

cablabel S3 demo

Test all functions of cablabel S3 Pro 30 days for free.

cablabel S3 demo download

Label printers SQUIX: Questions to Alexander Bardutzky

cab General Manager talks about development of SQUIX and Advanced Manufacturing.

Read the interview

SQUIX 4 MT details
Label printer SQUIX 4 MT

Technical details

Differences compared to a left-aligned material guide:

1 Ribbon holder
Easy insertion of the ribbons is enabled with the three-part tightening axles. A preprinted ruler simplifies the adjustment.

2 Roll holder
When setting the margin stop, the material roll is automatically centered. If rolls with 100 mm core diameter are processed, an adapter is recommended.

3 Plungers
Both plungers are fixed for all material widths. No print head settings or adjustments are necessary.

4 Antistatic brush
Particularly with plastic materials the electrostatic charge is discharged after printing.

5 Separator
At high heat energy the ribbon can stick with the textile tape. A roller reliably separates the material from the ribbon.

6 Material guide
The material guide just in front of the print roller provides accurate imprint. The material width is adjusted with a spindle.

DR4-M25     DR4-M25

DR4-M50     DR4-M50

DR4-M80     DR4-M80

Slim print rollers
To achieve accurate imprint with slim materials and ribbons slim print rollers are needed. These prevent from print roller wear, print head contamination and errors during material feed.

Coating: synthetic rubber



Operation panel

Intuitive and easy operation with self-explanatory symbols to configure the device setups

Operation panel1 LED signal: Power ON

2 Status bar: Data reception, Record data stream, Ribbon warning, SD memory card/USB memory stick plugged in, Bluetooth, WLAN, Ethernet, USB Slave, Time

3 Printer status: Ready, Pause, Number of printed labels per print job, Label in peel-off position, Awaiting external start signal

4 Periphery Periphery buttons:
Cutter/perforation cutter: direct cutting
External rewinder: winding outside or inside
Tear-off or peel-off mode: print the next label
Applicator: label application

5  Operation

Jump  Jump to menu

Reprint  Reprint last label

Interrupt   Interrupt and continue print job

Stop  Stop and delete all print jobs

Label feed  Label feed

6 USB slot for the Service Key or a memory stick, to load data in the IFFS storage

7 USB-WLAN-Stick 2.4 GHz 802.11b/g/n included as an extra item in the scope of delivery;
In hotspot mode it is possible to directly connect a mobile device with the printer via WLAN.


Setup optionsvergrößern
Setup options
Printing parametersvergrößern
Printing parameters
Print position Yvergrößern
Print position Y
Fast setup with a slider, fine setup with ± keys
Print speed selectionvergrößern
Print speed selection
via scroll function
Video tutorialsvergrößern
Video tutorials
Scan QR code with a mobile device and watch the explanatory video


Print heads

Print heads

All print heads are freely interchangeable at equal width. They are automatically detected and calibrated by the CPU.
Major data such as running performance, maximum operating temperature and heat energy are directly stored in the print head. The data can be read at the plant.

Print heads for SQUIX 2, SQUIX 4 - 300, 600 dpi
for a sharp-edge print image
for type plates with small fonts, graphics and material marking with high energy needs

Print heads for SQUIX 4.3, SQUIX 6.3 - 203, 300 dpi
durable, for rough surroundings and thermal direct printing

Maintenance

Cleaning of the label sensor
Label sensor

It can be unlocked with finger pressure and pulled out for cleaning.

Change of print head
Print head

Easy exchange in few simple steps. Adjustments or setups are basically not necessary.

Cleaning of print roller
Print roller

It can be easily unlocked with a screw for cleaning or replacement.

Assembly tool SQUIX

Assembly tool
ONE tool is provided with the printer to replace all components or to mount periphery.

Technical data SQUIX  with SQUIX M and SQUIX MP by comparison (PDF)

Typical Typical  Possible  Possible   standard Standard     Option Option

  1.5
Label printer SQUIX 4.3 MT SQUIX 4 MT
Material feed centered
Printing method: Thermal transfer Typical Typical Typical
Printing method: Thermal direct Typical Possible -
Printable resolution dpi 300 300 600
Print speed up to mm/s 250 300 150
Print width up to mm 108.4 105.7 105.7
Print start Distance to locating edge mm centered
Material
Roll, fanfold, reel: Paper, cardboard, PET, PE, PP, PI, PVC, PU, acrylate, Tyvec Typical
Roll, fanfold, reel: Smart Labels Possible
Roll, fanfold, reel: Ready-for-use shrink tubes Possible
Roll, fanfold, reel: Pressed continuous shrink tubes Possible
Roll, fanfold, reel: Textile tapes Typical
Labels1) Width mm 4 - 110
Labels    Height without label backfeed2) from mm 4
Labels    Height with label backfeed2) from mm 6
Labels Maximum height mm 2,000
Labels    Thickness mm 0.03 - 0.60
Carrier material Width mm 9  - 114
Carrier material Thickness mm 0.03 - 0.16
Continuous material Width mm 9  - 114
Continuous material Thickness mm 0.05 - 0.50
Continuous material Weight (cardboard) up to g/m2 300
Shrink tubes Width ready-for-use up to mm 114
Shrink tubes Width continuous mm 4 - 85
Shrink tubes Thickness up to mm 1.1
Roll, reel: Outside diameter with core diameter 205 / 38.1 - 76
180 / 100
Winding outside or inside
Ribbon3)
Ink side outside or inside
Roll diameter up to mm 80
Core diameter mm 25.4
Variable length up to m 450
Width mm 25-114
Printer sizes and weight
Width x Height x Depth mm 252 x 288 x 460
Weight kg 10
Label sensor with position indication
Gap sensor for labels, punch marks or print marks in transparent materials and end of material
Reflective sensor from below or top for print marks in not transparent materials and end of material
Distance sensor from center to locating edge centered mm 0-55
Height of material gap up to mm 2
Electronics
Processor 32 bit clock rate 800
Main storage (RAM) MB 256
Data storage (IFFS) MB 50
Slot for SD memory card (SDHC, SDXC) up to GB 512
Battery for time and date, real-time clock standard
Data storage when power is off (e.g. serial numbers) standard
USB WLAN stick 2.4 GHz 802.11b/g/n standard (included as an extra item in the scope of delivery)
Interfaces
RS232C 1,200 to 230,400 baud/8 bit standard
USB 2.0 Hi-speed device to connect a PC standard
Ethernet 10/100 BASE-T LPD, IPv4, RawIP printing, DHCP, HTTP, FTP, SMTP, SNMP, TIME, NTP, Zeroconf, SOAP web service, VNC
1 x USB host at the operation panel for
1 x USB host at the operation panel for
Service Key or USB memory stick
USB WLAN stick 2.4 GHz 802.11b/g/n
2 x USB host on the back side for Service Key, USB memory stick, keyboard, barcode scanner, USB Bluetooth adapter, USB WLAN stick
WLAN 802.11b/g/n, hotspot or infrastructure mode GHz 2.4 standard / 5
Periphery connection USB host, 24 VDC standard
Digital I/O with 8 inputs and outputs
Operating data
Power supply 100 - 240 VAC ~ 50/60 Hz, PFC
Power consumption Standby <10 W / typical 150 W / maximum 300 W
Temperature / humidity: Operation +5 - 40°C / 10 - 85% not condensing
Temperature / humidity: Storage 0 - 60°C / 20 - 85% not condensing
Temperature / humidity: Transport –25 - 60°C / 20 - 85% not condensing
Approvals CE, FCC class A, CB, CCC, cUL


Technical data SQUIX  with SQUIX M and SQUIX MP by comparison (PDF)

  1. Limitations may apply to small labels, thin materials or strong adhesives. Critical applications need to be tested.
  2. when tearing off, cutting, rewinding
  3. The ribbon should at least correspond with the width of the carrier material.

An overview of which accessories are compatible with which device version and which accessories can be adopted from the A + series you can find in the product brochure.
