Label printers SQUIX 4 MT
Particularly for textile materials

  • Reliable and quick printing
  • Accurate print images
  • Easy to operate
  • Compact design
  • Maximum quality standards

They find use in various areas of use. They have been developed with consistent focus on intuitive usability and highly reliable processing.

Print mechanics and chassis are made of high-quality materials and match perfectly in design and function. A wide range of peripherals and software enable user-specific solutions.

The rugged printers stand up to any demand, whether operated stand-alone, with a PC or in a network. Print jobs are performed quickly and labels are provided straight away thanks to a high-speed processor.

Label printers guiding materials in centered position and providing a separator

SQUIX 4 MTvergrößern
Basic unit

For textile operations

If operations require high heating, a ribbon may stick with the textile tape after printing. A draw roller separates the ribbon reliably from a material.

Labels and continuous materials wound on rolls or reels may be as well printed. Plungers do not have to be aligned for setting the width of a label. Adapted print rollers are provided for slim materials.

1.14 Label printer SQUIX 4.3 MT SQUIX 4 MT
Printable resolution dpi 300 300 600
Print speed mm/s max. 300 300 150
Print width mm max. 108.4 105.7 105.7

See also:

CenteredMaterial guide
centered

Left-alignedMaterial guide
left-aligned

SQUIX 4 M - Learn more SQUIX 4 M
especially very small labels or slim continuous materials

SQUIX 2, SQUIX 4, SQUIX 6 - Learn moreSQUIX 2, SQUIX 4, SQUIX 6
flexible printers for industrial applications in serveral widths



Video: Label printer SQUIX

for industrial applications

  View video

cabPROTECT

cab systems developed for printing and applying labels provide proper features by default, fairly protecting your data in a network.

Our security features

SOTI interface integrated by cab

SOTI Connect software enables label printers be configured and managed centrally.

Learn more

SQUIX 4 MT details
SQUIX 4 MT label printer
providing a separator built in

Technical details

Differences to other label printers
guiding materials in centered position



1 Antistatic brush
It dissipates electrostatic charge after printing, in particular if synthetic materials are in use.

2 Separator
If operations require high heating, a ribbon may stick with the textile tape after printing. A draw roller separates the ribbon reliably from a material.







Control panel

Self-explanatory symbols simplify settings and enable printers be operated intuitive and easily.

Operation panel1 LED: Power ON

2 Status bar: receive data, record data stream, prior warning to a ribbon ending, SD memory card / USB stick plugged, WLAN, Ethernet, USB slave, time

3 Printer status: ready, pause, number of labels printed in a print job, label peeled off, awaiting external start signal

4 USB port for plugging a service key or a memory stick, to transfer data to the IFFS memory

5 Operation

Cutter Cutter / perforation cutter: cutting
External rewinder: outside or inside winding
Tear-off mode / peel-off mode: printing a label
Applicator: printing and applying a label in individual steps

Jump  Jump to menu

Reprint  Reprint last label

Interrupt  Interrupt and continue print job

Stop  Stop and delete all print jobs

Label feed  Label feed


Printing parametersvergrößern
Printing parameters
Print position Yvergrößern
Print position Y
Print speed selectionvergrößern
Print speed
Video tutorialsvergrößern
Video tutorials


External control panel

If the control panel of a printer cannot be accessed, an additional external one can be plugged.

Same functionality as on the printer

Landscape or portrait mode

Operability as targeted, either on an external panel or on a printer

USB 2.0 Hi-Speed device for plugging a printer

1 LED: Power ON

2 USB port for plugging a service key or a memory stick, to transfer data to the IFFS memory

3 cab provides specified USB cables for power supply. Lengths are 1.8 m to 16 m

External operation panel

Print heads

Print heads

A print head can be replaced by any other one, provided they are of equal width. They are detected by the CPU and calibrated.
Major data such as operational performances, maximum operational temperatures and heating are kept in memory by the print head. The data can be read at the premise.

Print heads provided for SQUIX 2, SQUIX 4 - 300, 600 dpi
sharp-edged print images
small fonts, graphics on typeplates
printing on materials that imply high energy needs

Print heads provided for SQUIX 4.3, SQUIX 6.3 - 203, 300 dpi
Print heads provided for SQUIX 8.3 - 300 dpi

durable, printing in harsh environments, direct thermal printing

Maintenance

Cleaning of the label sensor
Label sensors

They can be unlocked by touch and pulled out for cleaning.

Change of print head
Print heads

They are easy to replace in few steps. In general, no adjustments are required.

Cleaning of print roller
Print rollers

They are quick and easy to loosen for cleaning or removal using a screw.

Assembly tool SQUIX

All-purpose tool
It is provided close at hand on a unit for replacing components and assembling periphery.

Technical data SQUIX: all models in comparision (PDF)

Typical typical  Possible  possible   standard standard     Option option

  1.15
Materials guided in centered position Type SQUIX 4.3 MT SQUIX 4 MT
Print method: Thermal transfer Typical Typical Typical
Direct thermal Typical Possible -
Printable resolution dpi 300 300 600
Print speed mm/s max. 300 300 150
Print width mm max. 108.4 105.7 105.7
Initial print Distance to locating edgemm centered
Material1)
Paper, cardboard, synthetics PET, PE, PP, PI, PVC, PU, acrylate, Tyvec Typical
Direct thermal paper / cardboard Typical Possible -
Shrink tube ready for use Possible
continuous,pressed Possible
Textile tape Typical
Finishing Roll, fanfold Typical
Roll diameter mm max. 205
Core diameter mm 38.1 - 76
Winding outside or inside
Label Width mm 4 - 110
Height no label backfeed2) mm at least 4
label backfeed2) mm at least 6
Thickness mm 0.03 - 0.6
Liner Width mm 9  - 114
Thickness mm 0.03 - 0.16
Continuous Width mm 9  - 114
Thickness mm 0.03 - 0.5
Weight (cardboard) g/m2 max. 300
Shrink tube Width ready for use mm max. 114
continuous, pressed mm 4 - 85
Thickness mm max. 1.1
Ribbon3) Color layer outside or inside
Roll diameter mm max. 80
Core diameter mm 25.4
Length m max. 600
Width mm 25 - 114
Printer dimensions, weights
Width x Height x Depth mm 252 x 288 x 460
Weight kg 10
Label sensors, position indicators
Transmissive sensor detecting labels, punch marks, materials ending, print marks on translucent materials
Reflective sensor from below or top detecting labels, materials ending, print marks on non-translucent materials
Sensor distance to locating edge centered position mm 0 - 55
Material passage mm max. 2 (5 are an option)
Interfaces
RS232C 1,200 to 230,400 baud/8 bit standard
USB 2.0 Hi-Speed device for plugging a PC standard
Ethernet 10/100 Mbit/s LPD, RawIP printing, SOAP web service, OPC UA, WebDAV, DHCP, HTTP/HTTPS, FTP/FTPS, TIME, NTP, Zeroconf, SNMP, SMTP, VNC
2 USB hosts on the control panel,
2 USB hosts on the back of a unit
Service key, USB stick, USB WLAN stick, USB WLAN stick with a rod antenna, keyboard, barcode scanner, external control panel (on back only)
USB host, 24 VDC, for peripheral plugging standard
Digital I/O interface providing 8 inputs and 8 outputs
Operating data
Voltage 100 - 240 VAC, 50/60 Hz, PFC
Consumption of power <10 W in standby / 100 W in typical operation / max. 200 W
Temperature / humidity: Operation +5 - 40°C / 10 - 85% not condensing
Stock 0 - 60°C / 20 - 85% not condensing
Transport –25 - 60°C / 20 - 85% not condensing
Approvals CE, FCC Class A, ICES-3, cULus, CB, CoC Mexico, CCC, BSMI, BIS, KC-Mark
Control panel
Color LCD touchscreen Diagonal 4.3
Resolution Width x Height px 272 x 480


Technical data SQUIX: all models in comparision (PDF)

  1. Specifications are standards. Operations including small, slim, thick or stiff materials need testing, so do strongly adhesive labels.
  2. if labels are torn off, cut, rewound
  3. A ribbon should be at least as wide as the liner material.
