FL+ marking lasers

FL+ LogoPrecise, fast, economic – cab fiber lasers

Performance and quality of a marking mainly relies on the output power and the laser beam‘s focusing. cab marking lasers FL+ are diode-pumped, air-cooled and offer highest beam quality and pulse peak power. An output power of the laser source of 10 up to 50 Watt is available.

Different plano-spherical lenses allow the lasers to mark in a field of 69x69 up to 290x290 mm. The lasers are used to mark on plastic, metal and color-coated surfaces.

The marking lasers FL+ consist of two fiber coupled functional modules: The scan head and the control unit with integrated laser source. The scan head may be assembled in each installation position. Control unit with integrated laser source is available in two different designs.

Two different designs

Marking laser FL+20Tvergrößern

Type 1 “Tower” for FL+20/30 Watt
Very compact design, used both as desktop version and for the integration into housings.

Marking laser FL+20Rvergrößern

Type 2 “Rack” for FL+10/20/30/50 Watt
Preferably used for the integration into 19“ cabinets. Control unit and laser source are incorporated in a 19“ rack mount.



Video: cab Laser-Integration 1 - Robotik

Laser Integration in Production Line with 5 - Axis Robot.

 Watch video

 More videos on laser integration

Laser safety housing LSG+100

The industrial solution that allows the marking of parts in series.

Learn more on LSG+100

Showcase Hannover Messe 2016

Marking on 'smart' key rings with cab fiber lasers.

Live at the SAP booth

Tower   1.2 1.3
Rack 2.1 2.2 2.3 2.4
  Marking laser FL+10 FL+20 FL+30 FL+50
Laser source Ytterbium fiber laser, pulsed, air-cooled
     cw output power max. W 10 20 30 50
     Pulse energy mJ 0.5 1 1 1
     Wave length nm 1064
     Beam quality M2 < 1.8
     Pulse width ns 90-120 80-120
     Pulse frequency kHz 20-80 2-200 2-200 2-200
     Fiber coupling m 4.5 2.5 2.5 2.5
Scan head
     Mounting Horizontal/vertical
     Marking speed mm/s ~5000
Pilot laser
     Wave length nm 650
     cw output power max. mW < 1
Electronics
     Processor 32 bit clock rate MHz 600
     Main memory (RAM) MB 256
     Data memory (Flash) MB 512
     Extensions (Flash) USB memory stick
  Dimensions and weights Tower Rack 4 RU 19“
Control unit HxWxD mm 312x150x410 178x420x420
Control unit weight kg 15 16
Scan head HxWxD mm 110x170x330
Scan head weight kg 7
 Control panel
Key switch Laser source ON/OFF
Push button pilot laser ON/OFF
Push button shutter open OPEN/CLOSE
Indicator emission Laser source active
Indicator laser error Laser source error
Indicator ready Laser source ready
Indicator power Power supply ON
Indicator pilot laser ON
Indicator shutter open Safety circuit open
Connection service USB mini
Connection data memory USB
Operating data FL+10 FL+20 FL+30 FL+50
Operating voltage/frequency 100-240 VAC ~ 50/60 Hz
Power ON/OFF
Power consumption standby W 65
Power consumption max. W 150 175 200 250
Temperature/humidity operation 5-40°C / 10-85% not condensing
Temperature/humidity stock 0-60°C / 20-80% not condensing
Temperature/humidity transport –25-60°C / 20-80% not condensing
Approvals CE, FCC class A, ICE S3
Performance level d
Laser safety class EN60825-1
Laser safety class laser source Class 4
Laser safety class pilot laser Class 2

Interfaces

Interfaces

For controlling and monitoring the process flow.

1. Ethernet 10/100 Base for PC. The device is supplied with a fixed IP address or configured in the DHCP mode.

2. Ethernet 10/100 Base for peripherals. For data communication from and to end devices.

3. + 4.  2 x RS232 C for peripherals. For data communication from and to end devices.

5. Digitale I/O for control and monitoring. Including eight freely programmable inputs and outputs. Protective circuit according to IEC 61131-2.

6. Remote for switching on and monitoring the laser.

7. Interlock/E-Stop for the integration into external safety lock and the connection to an external E-Stop according to performance level d.

Recommended system requirements PC

Computer IBM PC/AT compatible
Operating system Microsoft Windows 7 Professional SP1 (32/64 bit)
Processor Intel Core i3-540 or higher
Main storage Minimum 1 GB RAM, 2 GB or more recommended
Hard disc Memory requirements software 1 GB, recommended size of hard disc 40 GB or more
Drives CD-ROM/DVD drive for software installation
Interfaces Network card 10/100 Mbit for laser connection, PS2/USB interfaces for mouse/keyboard, USB 2.0 connection for dongle Options: USB 2.0 connection for storage medium, RS232 interface for cab axis systems or cab laser label marker LM+
Software cabLase Editor 5
Monitor SVGA, recommended resolution 1280x1024

Video: cab laser integration 1 - Robotics

Powered by YouTube. See all cab videos: cab channel on YouTube.



Other formats

Video: cab laser integration 2 - Robotics

Powered by YouTube. See all cab videos: cab channel on YouTube.



Other formats

Video: cab laser integration 3 - Vibration Conveyor

Powered by YouTube. See all cab videos: cab channel on YouTube.



Other formats

cab Laser Robo Marking Cell - LRMC

Powered by YouTube. See all cab videos: cab channel on YouTube.

Other formats



Download players:

Marking laser FL+ – Applications

cab FL+ marking lasers are primarily used for the processing of metal and plastic parts. Different methods are commonly used depending on the requirement and material.

Engraving

Ablation of the material through evaporation with very high energy density that produces a deep marking with contour sharpness. An additional color change depending on the alloy or chemical composition improves the readability of the marking contents.

QR codes for traceability

QR codes for traceability

Cast parts

Cast parts

Annealing

Is mainly used with high-alloy, stainless steels and with titanium. Laser annealing creates a color change when the material is selectively exposed to heat and oxygen without noticeable material ablation.

Medtech

Medtech

Traceability in sterilization processes

Traceability in sterilization processes

Surface removal

The laser marker removes top coating to show a different-colored material underneath. Examples: top coatings or anodizing layers, laser label material or day and night design on control buttons

Aluminum nameplates

Aluminum nameplates

Automotive components

Automotive components

Color change

Is used for the processing of plastic material. The color change depends on the chemical composition of the material and additives. Destroying color pigments and creating gas-bubbles within the material produces light marks. Carbonization produces dark marks.

Consumption meters

Consumption meters

Size allocation in medical technology

Size allocation in medical technology

Foaming

The laser beam melts the workpiece surface locally. Small gas bubbles increase the volume of the molten material producing a raised marking. Small gas bubbles within the material diffusely reflect the light.

Plastic ident clips

Plastic ident clips

Cable tags

Cable tags
